Features
Servo system: Optional hydraulic servo system.
Electrical control system: It is controlled by imported PLC and man-machine interface (in Chinese or English) and operated by color touch screen. All process setting, changing, searching, monitoring, and trouble diagnosis can be done on the touch screen. Non-contact working principle, the components are endurable.
Hydraulic system: t is controlled by proportional pressure and is provided with YUkEN hydraulic components, so it is consistent and reliable.
Plasticization system: Eficient plasticization twin-screw ensures sufficient and even plasticization.
Speed regulating system: Frequency variable regulating + alloy steel hard finishing reducer steadily regulate speed with low noise, so they are endurable.
Clamping system and die shifting system: Die shifting and clamping are done by clamping mechanism with double straight line trail, so it has high accuracy, low resistance and high speed.
Technical Parameter
| Name | Units | ABLB 75 I | ABLB 75 II |
| Max. product volume | L | 8 | 8 |
| Dry cycle | PC/H | 800 | 800*2 |
| Screw diameter | MM | 75 | 75 |
| Screw L/D ratio | L/D | 24 | 24 |
| Screw drive power | KW | 22 | 22 |
| Screw heating capacity | KW | 7-8 | 7-8 |
| No. of heating zone | ZONE | 4 | 4 |
| Output of HDPE | KG/H | 100 | 100 |
| Oil pump drive power | KW | 7.5 | 7.5 |
| Clamping force | KN | 80 | 80 |
| Max. size of mold | MM | 400×430 | 400×430 |
| Template size | MM | 380×420 | 380×420 |
| Mold stroke | MM | 170-520 | 170-520 |
| Max. die diameter | MM | 170 | 170 |
| Blowing pressure | MPA | 0.6 | 0.6 |
| Air volume | M³/MIN | 0.7 | 0.8 |
| Cooling water pressure | MPA | 0.3 | 0.3 |
| Water consumption | L/MIN | 60 | 80 |
| Size of machine | LxWxH | 4.2×2.0×2.7 | 4.2×2.2×2.7 |
| Weight of machine | TON | 6.8 | 7.5 |
Details and Construction
We break the limitations of standardized equipment and provide highly customized extrusion blow molding machines and comprehensive solutions to customers worldwide – customizing core parameters such as screw structure, die design, and automation level according to product specifications, production processes, and site conditions. Our equipment types cover the full range from single cavity to multi-cavity, from normal pressure to high pressure, and can meet different production needs such as small batch and multiple varieties, as well as large-scale mass production. At the same time, we have established a global service network, providing 24-hour remote fault diagnosis, rapid spare parts supply, regular inspection and maintenance services, etc., so that you can obtain timely and professional technical support anywhere in the world, ensuring worry-free production throughout the process.
