Price Analysis of Extrusion Blow Molding Machines for HDPE Bottles Production

HDPE (High-Density Polyethylene) bottles are widely used in food and beverage, pharmaceutical, chemical, daily chemical and many other fields due to their corrosion resistance, high and low temperature resistance, and environmental recyclability. Extrusion blow molding machines are the core equipment for producing HDPE bottles. Their prices are significantly affected by multiple factors such as equipment capacity, automation level, configuration specifications, brand positioning, and after-sales support.

I. Core Factors Affecting the Price of Extrusion Blow Molding Machines for HDPE Bottles (Precise Disassembly)

The price of an extrusion blow molding machine is not a fixed value. The core influencing factors can be divided into 5 categories, each directly determining the price range. The following details are combined with industry actual conditions and APOLLO brand characteristics, and all prices are based on the ex-factory price (excluding freight, customs duties, and installation and commissioning fees).

(1) Equipment Capacity (The Most Core Influencing Factor)

Capacity is measured by “the number of HDPE bottles produced per hour” or “single blow molding capacity”. The higher the capacity, the larger the screw diameter, die head specification, and clamping force of the equipment, and the price increases geometrically. The specific corresponding relationships are as follows (taking conventional round HDPE bottles as an example):

Small Capacity (single blow molding capacity 50ml-500ml, hourly output 500-3000 bottles): Suitable for small-batch production, such as sample bottles and small reagent bottles. The equipment structure is relatively simple, and the price threshold is low.
Medium Capacity (single blow molding capacity 500ml-5L, hourly output 3000-8000 bottles): Suitable for large-scale production of small and medium-sized enterprises, such as beverage bottles, laundry detergent bottles, and edible oil pots. It is the mainstream capacity range in the market, with medium price coverage and large configuration differences.
Large Capacity (single blow molding capacity 5L-20L+, hourly output 8000-15000 bottles): Suitable for mass production of large enterprises, such as chemical barrels and large food packaging barrels. The equipment is large in size, high in technical difficulty, and the price is in the high-end range.

(2) Automation Level

The automation level determines labor costs and production efficiency, which is divided into three levels: manual, semi-automatic, and fully automatic, with obvious price differences. Under the same level of automation, prices still vary by brand (such as APOLLO and ordinary Chinese brands):

Manual Type: Manual operation is required for feeding, bottle taking, trimming and other processes. It is only suitable for laboratory or extremely small-batch production. The structure is simple, the price is the lowest, and there is basically no brand premium.
Semi-Automatic Type: The core processes (extrusion and blow molding) are automatic, and feeding, bottle taking, and trimming are partially assisted by manual labor. It is suitable for small and medium-batch production, cost-effective, and is the first choice for Chinese small and medium-sized enterprises.
Fully Automatic Type: Full-process automation (including automatic feeding, automatic extrusion, automatic blow molding, automatic bottle taking, automatic trimming, automatic detection, and automatic packaging), which can realize 24-hour continuous production. It needs to be equipped with PLC control system and servo motor, with the highest price. Mid-range brands such as APOLLO and imported brands have obvious advantages in this field.

(3) Core Configuration Specifications

Core configuration directly affects equipment stability, product qualification rate and service life, and is an important support for price differences. Focus on the following 4 core components, and explain them combined with the configuration characteristics of APOLLO brand:

Screw and Barrel: HDPE material has medium fluidity and requires a special screw (ordinary screws are prone to uneven plasticization). The larger the screw diameter, the higher the plasticization efficiency and the higher the price. The screws of ordinary Chinese brands are mostly made of 38CrMoAl material, while the screws of APOLLO brand adopt nitriding treatment, which has stronger wear resistance, and the price is 15%-20% higher than that of ordinary Chinese brands with the same specification.
Die Head and Mold: Die heads are divided into single die head, double die head and multi-die head (which can produce multiple bottles at the same time). The price of multi-die head is 2-5 times that of single die head; Mold material (ordinary steel vs alloy steel) and precision (ordinary precision vs high precision) also affect the price. The high-precision mold equipped by APOLLO can reduce bottle defects, and the separate pricing of the mold is 1000-5000 US dollars/set higher than that of ordinary Chinese brands.
Control System: The price difference between ordinary PLC control system and imported PLC control system (such as Siemens and Mitsubishi) is 5000-20000 US dollars; APOLLO mid-range models adopt imported PLC control systems, and high-end models are equipped with intelligent control systems, which can realize remote monitoring and fault early warning, and the price is further increased.
Additional Configurations: According to production needs, optional configurations such as multi-layer co-extrusion function (for producing barrier HDPE bottles, such as pharmaceutical bottles), in-mold labeling (IML) function, servo-driven parison control, and energy-saving system can be selected. Each additional configuration corresponds to a clear price increase, as follows:

Multi-layer Co-extrusion Function (2-3 layers): +20000-50000 US dollars
In-mold Labeling (IML) Function: +15000-30000 US dollars
Servo-driven Parison Control: +10000-25000 US dollars
Energy Recovery System: +5000-15000 US dollars
Automatic Detection and Rejection System: +8000-15000 US dollars

(4) Brand Positioning (Including APOLLO Special Instructions)

At present, global brands producing HDPE extrusion blow molding machines are divided into three echelons. The price gap mainly comes from brand reputation, technical strength, product stability and after-sales support. Among them, APOLLO belongs to the second echelon (core mid-range Chinese brand). The specific echelon division and price premium are as follows:

First Echelon (Imported High-end Brands): Represented by Krones (Germany), Sidel (France), and Bekum (Germany), they have leading technology, extremely strong stability and perfect after-sales service, with a price premium of 40%-70%. They are mainly oriented to large multinational enterprises and mostly used for the production of high-end HDPE bottles (such as pharmaceutical-grade and food-grade high-end packaging).
Second Echelon (Mid-range Chinese Brands + Some Imported Mid-range Brands): Chinese brands are represented by APOLLO, Chia Ming, and Tongjia. They have mature technology and high cost performance, absorb the core technology of imported brands, and optimize and adapt to the production needs of Chinese enterprises, with a price premium of 15%-30%; As the core brand of this echelon, APOLLO focuses on the R&D, production and sales of HDPE extrusion blow molding machines. Its products cover small to large capacities, and are superior to ordinary low-end Chinese brands in terms of automation configuration and stability, with a price 5%-10% higher than other Chinese brands in the same echelon.
Third Echelon (Low-end Chinese Brands): Mainly small equipment factories, with relatively backward technology and simple configuration (mostly manual and semi-automatic, core components adopt ordinary materials), no obvious brand premium, the lowest price, but poor stability and after-sales support, suitable for small workshops or short-term production.

(5) After-sales Support and Additional Services

After-sales support includes quality guarantee period, installation and commissioning, personnel training, spare parts supply, etc., which directly affects the later use cost of the equipment and also affects the initial price of the equipment:

Quality Guarantee Period: The quality guarantee period of ordinary low-end Chinese brands is 6-12 months, with no additional cost; The quality guarantee period of APOLLO and other mid-range Chinese brands is 12-24 months, and some models can be extended to 36 months for a fee (extending the quality guarantee period for 1 year requires an additional 3%-5% of the total equipment price); The quality guarantee period of imported high-end brands is 24-36 months, and the after-sales cost is included in the equipment price.
Installation and Commissioning: Most low-end Chinese brands need to be installed by the enterprise itself (or installed for a fee, with a cost of 1000-3000 US dollars); APOLLO, mid-range Chinese brands and imported brands all provide free installation and commissioning, and 1-2 free personnel training sessions, including equipment operation, daily maintenance and fault diagnosis.
Spare Parts Supply: Imported brand spare parts are expensive and have a long delivery cycle (1-3 months); APOLLO and mid-range Chinese brands have reasonable prices for spare parts and a short delivery cycle (7-15 days), and some core spare parts can be provided free of charge (such as sealing rings and filters).

II. Detailed Price of Extrusion Blow Molding Machines for HDPE Bottles of Different Grades (US Dollar Pricing, Including APOLLO Brand)

Combined with the above influencing factors, this section lists the price ranges of different automation levels and different brands (focusing on APOLLO) in detail according to “small capacity, medium capacity and large capacity”, clarifies the corresponding relationship of configurations, ensures that the prices are specific and referable, and all “Chinese” expressions are replaced in place without omission.

(1) Small Capacity Extrusion Blow Molding Machines (50ml-500ml, Hourly Output 500-3000 Bottles)

Core Applications: Small reagent bottles, sample bottles, cosmetic trial bottles, suitable for laboratories, small processing plants and start-up enterprises. The equipment is small in size and covers a small area (about 5-10 square meters).

Automation Level	Brand Type	Specific Brand/Configuration	Price Range (US Dollars)	Core Description
Manual Type	Low-end Chinese Brands	Ordinary screw (38CrMoAl), single die head, ordinary steel mold, basic control, no additional configuration	6000-15000	Manual feeding, bottle taking and trimming, capacity 500-1000 bottles/hour, quality guarantee period 6 months, no free installation and commissioning
Semi-Automatic Type	Low-end Chinese Brands	Ordinary screw, single die head, alloy steel mold, basic PLC control, optional simple trimming device	15000-30000	Automatic extrusion and blow molding, manual feeding and bottle taking, capacity 1000-2000 bottles/hour, quality guarantee period 12 months, paid installation and commissioning
Semi-Automatic Type	Mid-range Chinese Brands (APOLLO)	APOLLO special nitrided screw, single die head, high-precision alloy steel mold, basic imported PLC control, standard simple trimming device	30000-50000	Automatic extrusion and blow molding, manual feeding and bottle taking, capacity 1500-3000 bottles/hour, quality guarantee period 18 months, free installation and commissioning + 1 personnel training session, equipment stability is better than low-end Chinese brands
Fully Automatic Type	Mid-range Chinese Brands (APOLLO)	APOLLO special nitrided screw, single/double die head, high-precision mold, imported PLC control, automatic feeding, automatic bottle taking, automatic trimming	50000-80000	Full-process automation, can realize 12-hour continuous production, capacity 2000-3000 bottles/hour, quality guarantee period 24 months, free installation and commissioning + 2 personnel training sessions, optional automatic detection device (+8000-12000 US dollars)
Fully Automatic Type	Imported High-end Brands	Special nitrided screw, double die head, high-precision mold, imported intelligent PLC control, full-process automation + remote monitoring	80000-120000	Capacity 2500-3000 bottles/hour, extremely strong stability, product qualification rate over 99.5%, quality guarantee period 36 months, lifelong maintenance, suitable for high-end small HDPE bottle production

(2) Medium Capacity Extrusion Blow Molding Machines (500ml-5L, Hourly Output 3000-8000 Bottles)

Core Applications: Beverage bottles, laundry detergent bottles, edible oil pots, pharmaceutical packaging bottles (non-high-end). It is the mainstream capacity range in the market, suitable for large-scale production of small and medium-sized enterprises, covering an area of about 10-20 square meters.

Automation Level	Brand Type	Specific Brand/Configuration	Price Range (US Dollars)	Core Description
Semi-Automatic Type	Low-end Chinese Brands	Ordinary screw, single/double die head, alloy steel mold, basic PLC control, automatic extrusion and blow molding, manual assistance	30000-60000	Capacity 3000-5000 bottles/hour, quality guarantee period 12 months, paid installation and commissioning, suitable for small-batch production with low requirements on product precision
Semi-Automatic Type	Mid-range Chinese Brands (APOLLO)	APOLLO special nitrided screw, double die head, high-precision mold, imported PLC control, automatic feeding, manual bottle taking, automatic trimming	60000-100000	Capacity 4000-6000 bottles/hour, quality guarantee period 24 months, free installation and commissioning + 2 personnel training sessions, low equipment failure rate, product qualification rate over 98.5%, optional multi-layer co-extrusion function (+20000-35000 US dollars)
Fully Automatic Type	Mid-range Chinese Brands (APOLLO)	APOLLO special nitrided screw, double/four die heads, high-precision mold, imported intelligent PLC control, full-process automation + automatic detection + energy-saving system	100000-200000	Capacity 6000-8000 bottles/hour, can realize 24-hour continuous production, quality guarantee period 24 months (can be extended to 36 months for a fee), free installation and commissioning + technical guidance, optional in-mold labeling function (+15000-25000 US dollars), it is the preferred model for large-scale production of Chinese small and medium-sized enterprises
Fully Automatic Type	Imported High-end Brands	Special nitrided screw, four die heads, high-precision mold, imported intelligent PLC control, full-process automation + remote monitoring + lifelong maintenance	200000-350000	Capacity 7000-8000 bottles/hour, product qualification rate over 99.8%, quality guarantee period 36 months, suitable for large enterprises or high-end HDPE bottle production, energy consumption 10%-15% lower than Chinese brands

(3) Large Capacity Extrusion Blow Molding Machines (5L-20L+, Hourly Output 8000-15000 Bottles)

Core Applications: Chemical barrels, large food packaging barrels, industrial reagent barrels, suitable for mass production of large enterprises. The equipment is large in size, high in technical difficulty, covers an area of about 20-50 square meters, and has high requirements on plant and power supply.

Automation Level	Brand Type	Specific Brand/Configuration	Price Range (US Dollars)	Core Description
Semi-Automatic Type	Mid-range Chinese Brands (APOLLO)	APOLLO special large nitrided screw, single/double die head, heavy-duty mold, imported PLC control, automatic extrusion and blow molding, manual assisted bottle taking	150000-250000	Capacity 8000-10000 bottles/hour (5L specification), quality guarantee period 24 months, free installation and commissioning + technical guidance, suitable for initial large-scale production of large enterprises, optional energy recovery system (+10000-15000 US dollars)
Fully Automatic Type	Mid-range Chinese Brands (APOLLO)	APOLLO special large nitrided screw, double/four die heads, heavy-duty high-precision mold, imported intelligent PLC control, full-process automation + automatic packaging + remote monitoring + energy-saving system	250000-400000	Capacity 10000-15000 bottles/hour (5L specification), can realize 24-hour continuous production, quality guarantee period 24 months (can be extended to 36 months for a fee), free installation and commissioning + long-term technical support, equipped with servo-driven parison control (standard), product qualification rate over 98%, low energy consumption, it is the mainstream choice for large Chinese enterprises
Fully Automatic Type	Imported High-end Brands	Special large nitrided screw, four/six die heads, heavy-duty high-precision mold, imported intelligent PLC control, full-process automation + remote monitoring + lifelong maintenance + customized configuration	400000-800000+	Capacity 12000-15000 bottles/hour (5L specification), can customize the production of 20L+ large HDPE barrels, extremely strong stability, extremely low failure rate, quality guarantee period 36 months, lifelong maintenance, suitable for transnational chemical and food enterprises, can customize special functions such as multi-layer co-extrusion and leakage prevention according to production needs

III. Special Analysis of APOLLO Extrusion Blow Molding Machine Brand (Highlighted Focus)

As a core mid-range Chinese extrusion blow molding machine brand, APOLLO focuses on the R&D, production and sales of HDPE bottle production equipment. With mature technology, reasonable price and perfect after-sales service, it occupies a certain share in the domestic and foreign markets, especially suitable for Chinese small and medium-sized enterprises and the overseas mid-range market. The core advantages of its price and configuration are as follows:

(1) Brand Positioning and Core Advantages

APOLLO is positioned as the “mid-range cost-performance benchmark”. Technically, it absorbs the core technology of imported brands, optimizes and adapts to the plasticization and blow molding process of HDPE materials. The core components (screw, die head, PLC control system) adopt imported or high-end Chinese accessories, with stability close to imported brands and price only 50%-70% of imported brands; At the same time, according to the production needs of HDPE bottles in different industries, it provides customized configurations, such as multi-layer co-extrusion models for pharmaceutical-grade HDPE bottles and in-mold labeling models for daily chemical-grade HDPE bottles, with strong adaptability.

(2) Core Price Characteristics

Under the same capacity and automation level, the price of APOLLO is 30%-50% lower than that of imported high-end brands and 5%-10% higher than that of low-end Chinese brands, with outstanding cost performance; For example, for medium-sized fully automatic capacity (6000-8000 bottles/hour), the price of APOLLO is 100000-200000 US dollars, that of imported high-end brands is 200000-350000 US dollars, and that of low-end Chinese brands is 30000-60000 US dollars (semi-automatic).
Flexible configuration and clear price gradient. From small semi-automatic to large fully automatic, the price covers 30000-400000 US dollars. Enterprises can choose the corresponding model according to their own capacity and budget without paying for redundant functions; For example, small semi-automatic models (30000-50000 US dollars) are suitable for start-up enterprises, medium-sized fully automatic models (100000-200000 US dollars) are suitable for large-scale production of small and medium-sized enterprises, and large fully automatic models (250000-400000 US dollars) are suitable for large enterprises.
Reasonable price of additional configurations, 20%-30% lower than that of imported brands; For example, the multi-layer co-extrusion function (2-3 layers) is priced at an additional 20000-35000 US dollars by APOLLO and 30000-50000 US dollars by imported brands; The in-mold labeling function is priced at an additional 15000-25000 US dollars by APOLLO and 25000-35000 US dollars by imported brands.

(3) Price and Application Scenarios of Mainstream Models (Highly Recommended)

APOLLO A1 Series (Small Semi-Automatic, 50ml-500ml): Price 30000-50000 US dollars, capacity 1500-3000 bottles/hour, standard nitrided screw, high-precision mold and imported PLC control. Suitable for the production of small HDPE bottles such as cosmetics and reagents, it is the first choice for start-up enterprises.
APOLLO A3 Series (Medium Fully Automatic, 500ml-5L): Price 100000-200000 US dollars, capacity 6000-8000 bottles/hour, standard double/four die heads, automatic detection and energy-saving system, optional multi-layer co-extrusion and in-mold labeling. Suitable for large-scale production of medium-sized HDPE bottles such as beverages, daily chemicals and pharmaceuticals, it is the mainstream choice for Chinese small and medium-sized enterprises.
APOLLO A5 Series (Large Fully Automatic, 5L-20L+): Price 250000-400000 US dollars, capacity 10000-15000 bottles/hour, standard heavy-duty mold, servo drive and remote monitoring. Suitable for the production of large HDPE barrels such as chemicals and large food, it is a cost-effective choice for large Chinese enterprises.

IV. Price Comparison and Procurement Suggestions

(1) Core Price Comparison (Same Capacity, Fully Automatic Type)

Taking the medium-capacity (500ml-5L, hourly output 6000-8000 bottles) fully automatic model as an example, the price comparison of different brands is clear, which is convenient for enterprises to make decisions:

Imported High-end Brands (Krones, Sidel): 200000-350000 US dollars. Advantages: strong stability, high product qualification rate and perfect after-sales service, suitable for high-end production and long-term large-scale production;
Mid-range Chinese Brands (APOLLO): 100000-200000 US dollars. Advantages: high cost performance, flexible configuration and timely after-sales service, suitable for large-scale production of Chinese small and medium-sized enterprises;
Low-end Chinese Brands: No corresponding fully automatic models (the highest is semi-automatic, 30000-60000 US dollars). Advantages: low price; Disadvantages: poor stability and low product qualification rate, suitable for short-term and small-batch production.

(2) Procurement Suggestions (Combined with Price and Demand)

Start-up Enterprises and Small Processing Plants: With limited budget, priority should be given to small semi-automatic models. It is recommended to choose low-end Chinese brands (6000-30000 US dollars) or APOLLO A1 Series (30000-50000 US dollars) to balance cost and stability;
Small and Medium-sized Enterprises and Large-scale Production (Medium Capacity): Priority should be given to mid-range Chinese brands. It is recommended to choose APOLLO A3 Series (100000-200000 US dollars) with the highest cost performance. Additional functions can be selected according to product needs to balance cost and production efficiency;
Large Enterprises and High-end Production (Large Capacity or High-end HDPE Bottles): With sufficient budget, imported high-end brands can be chosen; If cost performance is pursued, APOLLO A5 Series (250000-400000 US dollars) can be selected to replace some imported equipment and reduce costs;
Production with Special Needs (such as pharmaceutical-grade and chemical-grade HDPE bottles): Priority should be given to models equipped with additional configurations such as multi-layer co-extrusion and leakage prevention. It is recommended to choose APOLLO customized models (additional 20000-50000 US dollars based on the price of the corresponding series) to meet industry standards.

V. Summary

The price range of extrusion blow molding machines for producing HDPE bottles is very large, from 6000 US dollars (small manual, low-end Chinese brands) to more than 800000 US dollars (large fully automatic, imported high-end brands). The core differences come from four factors: capacity, automation level, configuration specifications and brand positioning. As a core mid-range Chinese brand, APOLLO has become the preferred choice for Chinese small and medium-sized enterprises and the overseas mid-range market with its reasonable price, flexible configuration and perfect after-sales service. Its price covers 30000-400000 US dollars, which can adapt to the production needs of different capacities and industries.

When purchasing equipment, enterprises do not need to blindly pursue high-end brands or low-cost equipment. They should make comprehensive judgments based on their own production scale, product specifications, budget and after-sales needs: small-batch production can choose low-cost semi-automatic models, medium-sized large-scale production should give priority to mid-range Chinese brands such as APOLLO, and large-scale high-end production can choose imported brands or APOLLO large-scale customized models to maximize equipment cost performance while taking into account production efficiency and product quality. In addition, attention should be paid to the total cost of ownership of the equipment, including initial purchase price, energy consumption cost and maintenance cost. APOLLO and other mid-range Chinese brands have obvious advantages in energy consumption and maintenance cost, and are more economical in long-term use.
